Modal

Table of Contents

Scrollable modal with sticky footer
Modal as alert dialog
Custom styling

If the modal's content does not fit within the available space, the content becomes scrollable and the footer area remains sticky.

Open Modal

Some Heading

Some Content Begin

Some Content End

Proceed

Cancel

Open in Stackblitz

<!doctype html>
<html lang="en" class="scheme-light-dark">
<head>
  <title></title>
</head>
<body class="bg-canvas">

<p-button type="button" aria="{'aria-haspopup': 'dialog'}">
  Open Modal
</p-button>

<p-modal aria="{'aria-label': 'Some Heading'}">
  <p-heading slot="header" size="large" tag="h2">
    Some Heading
  </p-heading>
  <p-text>
    Some Content Begin
  </p-text>
  <div class="w-[10px] h-[120vh] bg-[deeppink]"></div>
  <p-text>
    Some Content End
  </p-text>
  <div slot="footer" role="group" class="flex flex-wrap gap-fluid-sm max-xs:flex-col">
    <p-button type="button">
      Proceed
    </p-button>
    <p-button type="button" variant="secondary">
      Cancel
    </p-button>
  </div>
</p-modal>
<script>
  const pButton = document.querySelector("p-button");
  const pModal = document.querySelector("p-modal");
  pButton.addEventListener('click', () => (pModal.open = true));
  pModal.addEventListener('dismiss', () => (pModal.open = false));
</script>
</body>
</html>

The p-modal component can be used as an alert dialog. This is a modal dialog that interrupts the user's workflow to draw attention to an important message and requires a response.

Open Modal

Some important Heading

Some important Content

Deny

Open in Stackblitz

<!doctype html>
<html lang="en" class="scheme-light-dark">
<head>
  <title></title>
</head>
<body class="bg-canvas">

<p-button type="button" aria="{'aria-haspopup': 'dialog'}">
  Open Modal
</p-button>

<p-modal aria="{'role': 'alertdialog'}" disable-backdrop-click="true">
  <p-heading slot="header" size="large" tag="h2">
    Some important Heading
  </p-heading>
  <p-text>
    Some important Content
  </p-text>
  <div slot="footer" role="group" class="flex flex-wrap gap-fluid-sm max-xs:flex-col">
    <p-button type="button">
      Accept
    </p-button>
    <p-button type="button" variant="secondary">
      Deny
    </p-button>
  </div>
</p-modal>
<script>
  const pButton = document.querySelector("p-button");
  const pModal = document.querySelector("p-modal");
  pButton.addEventListener('click', () => (pModal.open = true));
  pModal.addEventListener('dismiss', () => (pModal.open = false));
</script>
</body>
</html>

Custom styling#

The modal component has some values that can be overridden via CSS custom properties (aka CSS variables). This might be useful, for example, for a "Cookie Consent Dialog" to reserve space when used with backdrop: 'shading' so that the Porsche crest or wordmark remains visible in the background of the page. Since the modal is centered within the viewport and shrinks to its content, the custom vertical spacing definition will act like a safe zone.

In addition, it is possible to make containers or elements (e.g. div, img, etc.) stretch into the padding safe zone by adding the CSS class.

// the modal comes with predefined margin / safe-zone which needs to be considered when a custom width is defined
--p-modal-width: clamp(276px, 45.25vw + 131px, 1000px);
--p-modal-spacing-top: 200px;
--p-modal-spacing-bottom: 50px;

Open Modal

Open in Stackblitz

<!doctype html>
<html lang="en" class="scheme-light-dark">
<head>
  <title></title>
</head>
<body class="bg-canvas">

<p-button type="button" aria="{'aria-haspopup': 'dialog'}">
  Open Modal
</p-button>

<p-modal backdrop="shading" aria="{'aria-label': 'Some Label'}" class="[--p-modal-width:clamp(276px,45.25vw+131px,1000px)] [--p-modal-spacing-top:200px] [--p-modal-spacing-bottom:50px]">
  <img src="assets/porsche-992-carrera-s.jpg" class="-mt-(--ref-p-modal-pt) -mx-(--ref-p-modal-px) -mb-(--ref-p-modal-pb)" />
</p-modal>
<script>
  const pButton = document.querySelector("p-button");
  const pModal = document.querySelector("p-modal");
  pButton.addEventListener('click', () => (pModal.open = true));
  pModal.addEventListener('dismiss', () => (pModal.open = false));
</script>
</body>
</html>
